Queue
Data Structure1128 views
Queue is an abstract data type or ordered collection of items where the addition of entities to the rear terminal position, known as enqueue, and removal of entities from the front terminal position, known as dequeue.
The most recently added item in the queue must wait at the end of the collection. The item that has been in the collection the longest is at the front. This ordering principle is sometimes called FIFO, first-in first-out. It is also known as "first-come first-served".
File Name: queue-algorithm.c
/* Enqueue */
If (REAR == N) Then [Check for overflow]
Print: Overflow
Else
If (FRONT and REAR == 0) Then [Check if QUEUE is empty]
(a) Set FRONT = 1
(b) Set REAR = 1
Else
Set REAR = REAR + 1 [Increment REAR by 1]
[End of Step 4 If]
QUEUE[REAR] = ITEM
Print: ITEM inserted
[End of Step 1 If]
Exit
/* Dequeue */
If (FRONT == 0) Then [Check for underflow]
Print: Underflow
Else
ITEM = QUEUE[FRONT]
If (FRONT == REAR) Then [Check if only one element is left]
(a) Set FRONT = 0
(b) Set REAR = 0
Else
Set FRONT = FRONT + 1 [Increment FRONT by 1]
[End of Step 5 If]
Print: ITEM deleted
[End of Step 1 If]
Exit
